E2W 200 KOMATSU Mechanical Press

Item Code: E2W 200
The E2W Straight Side Press
Designed for Superior Reliability and Consistency

The economical straight side with no compromise on performance. For jobs requiring larger beds for tooling, but lighter tonnage. Solid frame construction.

  • Ideal for progressive, transfer or manual die operations
  • True symmetrical unitized straight side frame
  • Superior rigidity characteristics
  • Superior off-center load charactersistics
  • Increased bearing slide guiding area
  • Faster stopping times with actual digital display
  • Higher production rates in single stroke mode
  • Higher counter balance capacity
  • Increased die life
A Higher Level of Standard Equipment for Increased Performance
  • Heavy plate, rigid frame construction
  • Bolster thickness exceeds JIC standards
  • Wide windows for transfer and progressive applications
  • Single-piece, heavy duty cast slide, prepared for knockouts
  • Precision plunger guide design
  • Push-button controlled, motorized slide adjustment
  • Mechanical slide lock mechanism
  • Eccentric drum main drive
  • Double gear reduction for greater torque capacity
  • Precision oil-lubricated long 6-point gibs
  • Hardened and ground helical gears
  • Pneumatic counter balance
  • Variable speed main motor
  • High-torque wet clutch and brake
  • Flywheel brake
  • Quick-responding, dependable hydraulic overload protector
  • Shock resistant, pendant-mounted control
  • T-stand for easy set-up and operation
  • 100 job memory
  • Safety block with interlock

Optional Features

Electronic Load Monitor  Load monitors are available to continuously monitor loads in all press operations, including blanking, bending, drawing, etc. The monitor also detects die overloads and underloads duing operation. In addition, balanced die load is achieved by measuring the off-center-load, thus extending press and die life.

  • Emergency Stop Receptacle
  • Die Cushions
  • Vibration Isolation Pad
  • Slide Knockout (mechanical)
  • Quick Die Change Equipment
    • Hydraulic die clamps available in either lever or cylinder type
    • Hydraulic die lifters
    • Mechanical draw out rails (note: re-machining of "T" slots may be required)
  • Presence-Sensing Safety Devices
  • Additional set of 4 Electronic Rotary Cams
  • Air Ejector with Cam
  • Adjustable Hydraulic Overload
  • Quick Die Change Interface
  • Coil Line Interface
  • Increased Job Storage Memory
